CRL 0681SC Satin Chrome End Cap Sliding Door Lock

This CRL Lock fits into the cut end of the DV146 ‘H’ Bar to secure the bypassing panels. Anti-Lift feature is obtained when using along with Cat. No. 6306 Anti-Lift Clip. No drilling of the glass is required. The Lock comes with two keys.
Product Warning:
The lock can be installed on either Left or Right Hand Doors by simply reversing the Tail piece.
*Inset Tail piece into desired end of the DV146 ‘H-Bar” (shoe) and secured in place by hand tightening down the small Allen head set screw.

.
