Brixwell GDH5BN Standard Mount Glass Door Hinge Brushed Nickel

Standard Mount Hinges are mounted in drilled holes in the cabinet frame. Set screws to secure the glass in hinge openings. Includes nylon bushings for drilled holes. Use Cat. No. GDH5J1G Drill Jig with Cat. No. GDH5WDFAB drill bit for quick, easy installation. Hinges are made of steel and the maximum weight per pair is 16 pounds (7 kg).
CRL's Stereo Cabinet Hardware is specifically designed for the fabrication of cabinets used for electronic components, china, or collectibles. All of the hardware is manufactured with precision to ensure a precise fit and years of service. The Hinges and Accessories are available in brass, chrome, and black which adapts to all wood finishes as well as another room décor. Our full line of Stereo Cabinet Accessories will enable you to coordinate the style and color for all your hardware requirements. All components are designed to work with 3/16" (5 mm) tempered glass.
SPECIFICATIONS:
Glass Height: Opening Minus 3/8" (10 mm)
Single Door Width: Opening Minus 3/32" (2.4 mm)
Double Door Width: Opening Divided by 2, Minus 5/64" (2 mm). Maximum Door Dimensions 18" (457 mm) W x 39" (991 mm) H. Important Notes: The dimensions are merely guidelines that should be satisfactory in most cases. For a very tight fit, you should calculate your own dimensions.
